Упутство за употребу Emerio MS-125000 вишенаменске секалице

Увод

Thank you for choosing the Emerio MS-125000 All-Purpose Slicer. This manual provides essential information for the safe and efficient operation, maintenance, and care of your new appliance. Please read these instructions thoroughly before first use and keep them for future reference.

The Emerio MS-125000 is designed for slicing various food items such as bread, cheese, cold cuts, and vegetables. Its foldable design ensures space-saving storage, and the adjustable cutting width allows for precise slicing from 0 to 17 mm.

Важна безбедносна упутства

УПОЗОРЕЊЕ: Непоштовање ових безбедносних упутстава може довести до струјног удара, пожара или озбиљних повреда.

• Always ensure the appliance is unplugged from the power outlet before assembly, disassembly, cleaning, or when not in use.
• Keep hands and utensils away from the moving blade during operation. The blade is extremely sharp.
• Овај уређај није намењен за употребу од стране особа (укључујући децу) са смањеним физичким, чулним или менталним способностима или недостатком искуства и знања, осим ако им је дат надзор или упутства о употреби уређаја од стране особе одговорне за њихову безбедност .
• Децу треба надзирати како би се осигурало да се не играју са уређајем.
• Do not operate the slicer if the power cord or plug is damaged, or if the appliance malfunctions or has been dropped or damaged in any manner. Contact customer service for repair.
• Не урањајте јединицу мотора у воду или било коју другу течност.
• Use the food pusher to guide food. Never use your hands directly to push food towards the blade.
• Ensure the slicer is placed on a stable, flat, and dry surface during operation.
• The device only works if both safety switches are pressed simultaneously. This is a safety feature to prevent accidental activation.
• Овај уређај је само за употребу у домаћинству. Немојте користити на отвореном.

Производ је завршенview

The Emerio MS-125000 All-Purpose Slicer features a robust design with a stainless steel knife unit and BPA-free plastic components for your health and safety.

Figure 1: The Emerio MS-125000 All-Purpose Slicer unfolded and ready for operation. This image shows the main body, the circular stainless steel blade, and the food carriage.

Figure 2: The slicer positioned with various food items, demonstrating its versatility for slicing different ingredients.

Figure 3: The slicer in its folded position, highlighting its space-saving design for easy storage.

Слика 4: Детаљан view of the manual cutting width adjustment mechanism, showing settings from 0 to 17 mm.

Слика 5: Бочни професионалацfile of the slicer, illustrating its sleek design and how it stands when unfolded.

Слика 6: Задња страна view of the slicer in its folded state, demonstrating how it can be stored compactly.

Figure 7: Top-down perspective of the slicer, providing a clear view of the blade and the area where food is placed for slicing.

Слика 8: Предња страна view of the slicer, detailing the blade guard and the general appearance from the user's perspective.

Подешавање и прва употреба

1. Распакивање: Carefully remove the slicer from its packaging. Retain packaging materials for future storage or transport.
2. Прво чишћење: Пре прве употребе, очистите све делове који ће доћи у контакт са храном. Погледајте одељак „Одржавање и чишћење“ за детаљна упутства.
3. Unfolding the Slicer: Place the slicer on a stable, flat, and dry surface. Gently unfold the appliance until it locks into its operating position. Ensure all components are securely in place.
4. Blade Installation (if applicable): Ensure the stainless steel blade is correctly and securely installed. Refer to the diagram in the "Product Overview" section for proper placement.
5. Прикључак за напајање: Укључите кабл за напајање у одговарајућу уземљену електричну утичницу. Уверите се да је јачина звукаtagе одговара спецификацијама уређаја.

Упутство за употребу

1. Adjusting Cutting Width: Locate the cutting width adjustment knob/lever (refer to Figure 4). Rotate or slide it to select your desired slice thickness, from 0 to 17 mm. Start with a thicker setting and adjust as needed.
2. Постављање хране: Place the food item to be sliced onto the food carriage. Use the food pusher to secure the food against the guide plate.
3. Activating the Slicer: The Emerio MS-125000 features a safety switch mechanism. To operate, you must press and hold обоје safety switches simultaneously. The blade will begin to rotate.
4. Сечење: While holding both safety switches, gently push the food carriage forward and backward, guiding the food against the rotating blade. Apply even pressure for consistent slices.
5. Заустављање рада: Release the safety switches to stop the blade. Always wait for the blade to come to a complete stop before removing sliced food or adjusting settings.
6. Removing Sliced Food: Carefully remove the sliced food from the collection tray.

Напомена: For optimal results and safety, always use the food pusher. Never attempt to slice frozen foods or foods with bones.

Одржавање и чишћење

WARNING: Always unplug the slicer from the power outlet before cleaning.

1. Растављање: Carefully disassemble the removable parts, such as the food carriage, food pusher, and blade (if designed for easy removal). Refer to your specific model's instructions for blade removal, as it may vary.
2. Чишћење оштрице: The stainless steel blade is extremely sharp. Use caution when handling. Clean the blade with a damp cloth and mild detergent. For thorough cleaning, some blades may be removable and dishwasher safe, but always check your specific model's manual. For this model, само ручно прање is recommended for the blade and other parts.
3. Тело уређаја: Wipe the main body of the slicer with a damp тканина. Не урањајте јединицу мотора у воду.
4. Сушење: Уверите се да су сви делови потпуно суви пре поновног склапања или складиштења уређаја.
5. Поновно састављање: Reassemble the slicer, ensuring all parts are correctly and securely fitted.

Упутства за одржавање производа: Hand Wash Only for all parts that come into contact with food.

Складиштење

The Emerio MS-125000 All-Purpose Slicer is designed to be foldable for space-saving storage.

1. Ensure the slicer is clean and dry before storing.
2. Adjust the cutting width to the '0' or fully closed position to protect the blade.
3. Carefully fold the slicer according to its design. Refer to Figure 3 and Figure 6 for visual guidance on the folded state.
4. Уређај чувајте на сувом, безбедном месту, ван домашаја деце.

Решавање проблема

Спецификације

• Модел: МС-125000
• Бренд: Емерио
• Снага: 100 Ваттс
• Димензије производа (Д к Ш к В): 33 Д к 19.6 Ш к 25 В центиметара
• Тежина артикла: 1.4 килограма
• Материјал: Пластика, нерђајући челик
• Материјал сечива: нерђајући челик
• Дужина сечива: 17 Millimetres (referring to cutting thickness range)
• Cutting Width Adjustment: 0-17 мм
• Посебне карактеристике: Foldable, Space-Saving, BPA-Free plastic parts, Safety Switch
• Порекло: Device "Made in Europe", Knife unit "Made in Germany"
• Упутства за негу: Само ручно прање

Гаранција и подршка

Emerio products are manufactured to high-quality standards. In the unlikely event of a defect or malfunction, please refer to your purchase documentation for warranty details. For technical support, spare parts, or service inquiries, please contact your local Emerio distributor or the retailer where the product was purchased.

Please have your model number (MS-125000) and proof of purchase ready when contacting support.
