Увод
Welcome to the Oclean Kids Electric Toothbrush Air 2 user manual. This guide provides essential information for the safe and effective use of your new electric toothbrush. Designed for children aged 6 and above, the Oclean Air 2 features advanced sonic technology for thorough cleaning and a quiet brushing experience.
Пажљиво прочитајте ово упутство пре прве употребе и сачувајте га за будућу употребу.
Шта је у кутији
Your Oclean Kids Electric Toothbrush Air 2 package includes the following components:
- Oclean Kids Electric Toothbrush handle (x1)
- Toothbrush Head (x2)
- USB Magnetic Charge Base (x1)
- Упутство за употребу (к1)
Сетуп
1. Пуњење четкице за зубе
Before first use, fully charge the toothbrush. The Oclean Air 2 features a fast-charging capability.
- Connect the USB Magnetic Charge Base to a compatible USB power adapter (not included).
- Place the toothbrush handle onto the magnetic charge base. Ensure proper contact.
- The indicator light on the toothbrush will show charging status. A full charge takes approximately 2.5 hours and provides up to 40 days of use.
Image: Patented Maglev Motor. This image shows a transparent view of the toothbrush handle, highlighting the internal patented maglev motor, which delivers up to 80,000 movements per minute for effective cleaning.
2. Причвршћивање главе четкице
- Поравнајте главу четкице са металном осовином на дршци четкице за зубе.
- Чврсто притисните главу четкице надоле док не кликне на место.
Image: Tailor-Made Brush Head. This image displays the specially designed brush head for kids, featuring soft DuPont & Pedex bristles, some infused with fluoride, and a rubber-covered base for safety and comfort.
Упутство за употребу
Укључивање/искључивање и избор режима
The Oclean Air 2 features a single-button operation for simplicity.
- Да бисте укључили/искључили: Кратко притисните дугме за напајање.
- Да бисте променили режиме: Long-press the power button for 2 seconds while the toothbrush is on. The toothbrush offers two cleaning modes:
- Gentle Clean Mode: Ideal for sensitive gums or initial use.
- Standard Brushing Mode: Provides up to 80,000 movements per minute for daily thorough cleaning.
Техника четкања
- Навлажите главу четкице и нанесите малу количину пасте за зубе.
- Place the brush head against the teeth at a slight angle towards the gum line.
- Turn on the toothbrush. Gently move the brush head slowly across each tooth, allowing the sonic vibrations to clean. Do not scrub.
- The toothbrush includes a 2-minute smart timer and a 30-second reminder to guide brushing in all four quadrants of the mouth.
- The built-in AI pressure sensor helps protect gums and teeth by alerting if too much pressure is applied.
Image: AI Pressure Sensor. This graphic illustrates the AI pressure sensor feature, showing how it detects excessive force during brushing to protect teeth and gums.
Image: Ultra Quiet Technology. This image shows a child sleeping peacefully while the Oclean toothbrush is in use, emphasizing its ultra-quiet operation (under 37 dB) due to Whisperclean technology.
Одржавање
Чишћење четкице за зубе
Regular cleaning ensures hygiene and extends the life of your toothbrush.
- Након сваке употребе, темељно исперите главу четкице под млазом воде.
- Remove the brush head and rinse the metal shaft area.
- Обришите дршку четкице за зубе огласомamp cloth. The toothbrush is IPX7 waterproof, allowing it to be safely rinsed under water.
- Allow all parts to air dry before storing.
Замена главе четкице
Dentists recommend replacing brush heads every 3 months, or sooner if the bristles become frayed.
Решавање проблема
| Проблем | Могући узрок | Решење |
|---|---|---|
| Четкица за зубе се не укључује. | Батерија је празна. | Charge the toothbrush fully using the magnetic charge base. |
| Weak vibration or reduced performance. | Low battery or brush head is worn. | Recharge the toothbrush. Replace the brush head if bristles are frayed. |
| Toothbrush stops during use. | Battery is low or automatic timer has completed. | Recharge the toothbrush. If the 2-minute timer has finished, simply restart for further cleaning if desired. |
| Brush head feels loose. | Глава четкице није правилно причвршћена. | Remove and re-attach the brush head, ensuring it clicks firmly into place. |
Спецификације
| Феатуре | Детаљ |
|---|---|
| Број модела | OC-Kids Air2-Pink |
| Бранд | Оцлеан |
| Димензије (ДкШкВ) | 25 x 25 x 235 милиметара |
| Тежина артикла | 95g (toothbrush body) / 349 g (package weight) |
| Извор напајања | Напајање на батерије (пуњиво) |
| Капацитет батерије | 800mAh (уграђена) |
| Време пуњења | Прибл. 2.5 сата |
| Трајање батерије | Up to 40 days (based on typical use) |
| Водоотпорна оцена | ИПКС7 |
| Режими четкања | 2 (Gentle Clean, Standard Brushing) |
| Покрети у минути | До 80,000 |
| Ниво буке | Under 37 dB (Whisperclean Technology) |
| Посебне карактеристике | AI Pressure Sensor, 2-minute Smart Timer, 30-second Reminder, Magnetic Charge Base |
| Бристле Материал | Ultra Soft DuPont & Pedex |
| Аге Ранге | 6+ година |
Гаранција и подршка
For warranty information, product support, or to purchase replacement parts and accessories, please visit the official Oclean website or contact Oclean customer service directly. Keep your purchase receipt as proof of purchase.
Произвођач: Оцлеан
Број дела ставке: OC-Kids Air2-Pink
