eMylo CT90R Solar Motion Sensor Alarm Outdoor Instruction Manual

Увод

The eMylo CT90R Solar Motion Sensor Alarm is designed to provide security for various outdoor and indoor environments. It features a 120dB alarm, strobe lights, remote control operation, and is IP65 waterproof. This manual provides instructions for the proper setup, operation, and maintenance of your device.

The eMylo Solar Motion Sensor Alarm provides security by detecting movement around your property.

The alarm is suitable for a wide range of applications including gardens, farms, yards, and orchards.

Карактеристике производа

• Professional Motion Sensor: Utilizes advanced infrared detection technology with a 110° detection angle and up to 19.69 ft (6m) detection distance.
• High-Volume Alarm & Strobe Lights: Activates a 120dB alarm sounder with flashing warnings upon motion detection.
• Подесива јачина звука: Choose between high, medium, and low volume levels to suit your environment.
• Три начина рада: Offers 24-hour all-day alarm, daytime alarm/nighttime non-alarm, and nighttime alarm/daytime non-alarm modes for flexible security.
• ИП65 водоотпоран: Designed with an IP65 waterproof rating, making it suitable for year-round outdoor use in various climate conditions.
• Опције двоструког пуњења: Supports solar charging via the integrated panel and USB Type-C charging (built-in 1000mAH battery).
• Подесива осетљивост: Features two sensitivity levels (high: 9-12m, low: 5-8m) to effectively reduce false alarms.
• даљински управљач: Conveniently arm, disarm, adjust volume, and switch modes from a distance.

The alarm produces a loud 120dB sound, comparable to a car horn, to deter intruders.

The device offers long-range detection with a 110-degree angle and is IP65 waterproof for outdoor reliability.

Производ је завршенview and Remote Control Functions

Familiarize yourself with the components of the eMylo Solar Motion Sensor Alarm and its remote control for effective operation.

Детаљно view of the alarm unit's components and the remote control's functions.

Инсталација

The eMylo Solar Motion Sensor Alarm is designed for fixed installation, typically wall-mounted. Ensure the chosen location allows the solar panel to receive adequate direct sunlight for optimal charging and that the detection area is clear of obstructions.

Укључивање/искључивање

To power on the device, locate the power button on the back of the unit (within the blue compartment) and long-press it for 3 seconds. The alarm light will flash once, and you will hear a beep, indicating it is powered on. To power off, repeat the same long-press action.

Operating the Alarm (Arm/Disarm)

Use the remote control to conveniently arm or disarm the alarm system.

Разоружај

Притисните тастер "disarm" button (green unlocked padlock icon) on the remote control to release the device from alert mode. In this mode, the device will not sound an alarm when sensing human movement.

Арм

Притисните тастер "arm" button (orange locked padlock icon) on the remote control to enter the alert mode. The device will sound an alarm when sensing human movement.

Радни режими

The eMylo alarm offers three distinct working modes. You can switch modes using the button on the back of the product or quickly via the remote control. When using the remote, ensure it is aligned with the product.

The alarm supports three distinct working modes to suit different security needs.

Mode 1: 24-hour Working Mode

In this mode, the alarm is active 24 hours a day. It will detect motion and trigger the alarm both during the day and at night.

Mode 2: Daytime Working Mode

This mode activates the alarm only during daytime hours. It will not trigger an alarm at night.

Mode 3: Night Working Mode

This mode activates the alarm only during nighttime hours. It will not trigger an alarm during the day.

Пуњење

The eMylo alarm supports two convenient charging methods to ensure continuous operation:

• Соларно пуњење: The integrated solar panel charges the internal 1000mAH battery when exposed to sunlight. Charging time depends on sun exposure and intensity (typically >24 hours for a full charge). When charging, the alarm light will light up slightly.
• УСБ пуњење: For faster or indoor charging, use the included USB Type-C cable. A full charge via USB takes approximately 8 hours.

The alarm can be charged via its solar panel or through a USB-C connection.

The device is designed for solar charging and is waterproof for outdoor use.

Adjusting Volume and Sensitivity

Подешавање јачине звука

The alarm volume can be adjusted to high, medium, or low using the buttons on the back of the product or via the remote control. Ensure the remote is aligned with the product for operation.

Подешавање осетљивости

The device features two sensitivity levels to minimize false alarms and optimize detection for different scenarios:

• Висока осетљивост: Detects motion from 9-12 meters, suitable for larger areas or detecting smaller movements.
• Ниска осетљивост: Detects motion from 5-8 meters, useful for reducing triggers from small animals or distant movements.

Adjust the sensitivity to differentiate between various sizes of movement, such as small animals versus humans.

Спецификације

Одржавање

Proper maintenance ensures the longevity and optimal performance of your eMylo Solar Motion Sensor Alarm.

• Keep the solar panel clean and free from dust, leaves, or other debris to ensure efficient charging.
• Regularly check the motion detection window for any obstructions that might interfere with its operation.
• Ensure the device is securely mounted to prevent accidental falls or damage.
• If the device is not in use for an extended period, store it in a dry, cool place.

Решавање проблема

If you encounter any issues with your eMylo Solar Motion Sensor Alarm, refer to the following common troubleshooting steps:

• Alarm not sounding/flashing: Ensure the device is powered on and in an armed working mode. Check the battery level and charge if necessary. Verify that the motion detection area is not obstructed.
• Лажни аларми: Adjust the sensitivity to a lower setting. Ensure the device is not pointed at moving objects like tree branches, reflective surfaces, or areas with frequent non-threatening movement.
• Даљински управљач не ради: Ensure the remote control battery is functional. Point the remote directly at the alarm unit for optimal signal reception.
• Poor solar charging: Relocate the device to an area with more direct and prolonged sunlight exposure. Clean the solar panel surface.

Гаранција и подршка

eMylo is committed to providing quality products and customer satisfaction. For any issues, questions, or technical support, please utilize the 24-hour customer service. Refer to the contact information provided with your product packaging or visit the official eMylo webсајт за помоћ.

Please retain your purchase receipt as proof of purchase for any warranty claims. The manufacturer warranty description is 1 year from the date of purchase.
