Pxwaxpy 7000mAh Battery Case User Manual

1. Увод

Thank you for choosing the Pxwaxpy 7000mAh Battery Case. This product is designed to extend your iPhone's battery life while providing protection. Please read this manual carefully before use to ensure proper operation and longevity of your device.

1.1 Компатибилност

This battery case is specifically designed for the following iPhone models (4.7-inch screen size):

• иПхоне 6
• иПхоне 6с
• иПхоне 7
• иПхоне 8
• iPhone SE (2020 Version)
• iPhone SE (2022 Version)

Важна напомена:

• This case is НЕ compatible with any other iPhone models, including Plus versions (e.g., iPhone 6 Plus, 7 Plus, 8 Plus).
• Има НЕ support Qi wireless charging.
• Има НЕ support CarPlay.

Image: Visual guide for compatible iPhone models (4.7-inch) versus incompatible larger models (5.5-inch).

1.2 Кључне карактеристике

• 7000mAh High Capacity Battery: Provides significant extended battery life for your iPhone.
• Advanced Sync-Data Technology: Allows data synchronization with your computer without removing the case.
• Charging & Protection 2-in-1: Functions as both an external battery pack and a protective case.
• Integrated Safety Circuits: Protects against overcharging, overheating, over-current, and short-circuits.
• Soft Top TPU Material: Facilitates easy installation and removal of your iPhone.
• 360° потпуна заштита: Bumper and hard shell design with raised bezels and a tempered glass screen protector for comprehensive device protection.

Image: The Pxwaxpy 7000mAh battery case providing additional power to an iPhone.

2. Садржај пакета

Молимо вас да проверите пакет за следеће ставке:

• Pxwaxpy 7000mAh Battery Case for iPhone 6/6s/7/8/SE (2020/2022) (4.7 Inch) x 1
• Tempered-Glass Screen Protector x 1
• Упутство за употребу к 1

3. Подешавање

3.1 Initial Charging of the Battery Case

Before first use, fully charge the battery case using your original iPhone charging cable. Connect the charging cable to the case's charging port and a power source. The LED indicators will show the charging progress.

3.2 Installing Your iPhone

1. Gently bend the soft TPU top part of the battery case backward.
2. Slide your iPhone vertically into the battery case from the top, ensuring the charging connector aligns properly.
3. Push the iPhone firmly until it is fully seated and the soft top part snaps back into place.

Image: Step-by-step guide for installing and removing the iPhone from the battery case.

4. Упутство за употребу

4.1 Пуњење вашег iPhone-а

To start or stop charging your iPhone using the battery case, press and hold the power button on the back of the case for approximately 3 seconds. The LED indicators will illuminate to show the charging status.

4.2 Провера нивоа батерије

The battery case features four LED indicator lights on the back that display the current power level:

• 1 ЛЕД: Преостало 1% - 25% батерије
• 2 ЛЕД диоде: Преостало 25% - 50% батерије
• 3 ЛЕД диоде: Преостало 50% - 75% батерије
• 4 ЛЕД диоде: Преостало 75% - 100% батерије

Image: Explanation of the LED indicator lights for battery level.

4.3 Синхронизација података

The battery case supports data synchronization. You can connect your iPhone (while in the battery case) to a computer (MacBook, PC, or laptop) using your original charging cable to sync data without needing to remove the case.

Image: Data synchronization and charging of the iPhone while in the battery case.

5. Одржавање

• Keep the battery case dry and away from moisture.
• Avoid exposing the case to extreme temperatures (hot or cold).
• Clean the case with a soft, dry cloth. Do not use harsh chemicals or abrasive cleaners.
• Чувајте кућиште на хладном и сувом месту када се не користи.
• For optimal battery health, fully charge and discharge the case at least once every three months if stored for extended periods.

КСНУМКС. Решавање проблема

Q: The battery case is not charging.

A: Ensure you are using your original iPhone charging cable. Check if the cable is securely connected to both the case and the power source. Try a different cable or power adapter.

Q: My iPhone is not charging when in the case.

A: Make sure your iPhone is correctly seated in the case and the charging connector is fully engaged. Press and hold the power button on the back of the case for 3 seconds to activate charging. Check the battery level indicators on the case.

Q: The case feels warm during charging or use.

A: It is normal for the battery case to generate some heat during charging or discharge. If the case becomes excessively hot, disconnect it immediately and contact customer support. The case has integrated protection against overheating.

Q: My iPhone SE (2020/2022) charges slowly.

A: The battery case provides standard charging output (5V 1A). Newer iPhone models like the SE (2020/2022) can support faster charging. While the case will charge your phone, the speed may be slower compared to direct connection with a higher-wattage charger, especially during heavy usage.

Q: The screen protector was damaged or missing.

A: Please contact customer support for assistance with replacement or further instructions.

7. Спецификације

8. Безбедносне информације

To ensure safe operation and prevent damage to your device or injury, please observe the following:

• Do not disassemble, modify, or repair the battery case yourself.
• Avoid dropping, puncturing, or crushing the case.
• Keep away from fire, water, and corrosive liquids.
• Do not expose to direct sunlight or high temperatures for extended periods.
• Dispose of the battery case according to local regulations for electronic waste.

Image: Visual representation of the superior safety protection features of the battery case.

9. Гаранција и подршка

Pxwaxpy provides a 24-month after-sale technical support и а 30-day no-hassle return or refund policy. We are committed to providing 7/24H online service and lifetime technology support to ensure your satisfaction.

For any questions, concerns, or technical assistance, please contact our customer support team through the platform where you purchased the product.
