Enyuly HBL6310 Battery Replacement User Manual

1. Увод

This manual provides essential instructions for the safe and effective use of your Enyuly HBL6310 replacement battery. Please read this manual thoroughly before installation and operation to ensure proper function and longevity of the product.

2. Важне информације о безбедности

Observe the following safety precautions to prevent injury or damage to the battery and device. Failure to follow these instructions may result in fire, explosion, electric shock, or other hazards.

• CAUTION: WARRANTY VOID IF LABEL IS REMOVED.
• НЕМОЈТЕ attempt to disassemble, open, or service the battery pack.
• REPLACE ONLY with the battery pack designated for this product.
• НЕМОЈТЕ згњечити, пробити, кратки спољни контакти или бацити у ватру или воду.
• НЕМОЈТЕ store above 60°C (140°F).
• ПАЖЊА: NEW BATTERY PACK MUST BE FULLY CHARGED BEFORE USE.
• TO REDUCE RISK OF FIRE OR BURNS, read instructions in operating guide before using the battery.
• Лимитед Цхарге Волtage: 4.35V ±0.05V. Standard: GB 31241-2014.

Manufacturer: ShenZhen HENZENS Technology Co., Limited.

За више информација посетите Cameron Sino.

Опис слике: A detailed close-up of the Enyuly HBL6310 Li-Polymer battery's black label, clearly showing the model number, part number, rating (3.8VDC, 3650mAh, 13.87Wh), and critical safety warnings and instructions. The 'Made in China' mark and various certification symbols are also visible. This image emphasizes the important text on the battery itself.

3. Производ је готовview

The Enyuly HBL6310 is a high-capacity Li-Polymer replacement battery designed for specific Urovo devices, offering reliable power and extended usage.

Опис слике: A top-down, slightly angled view of the Enyuly HBL6310 Li-Polymer battery pack. The battery is rectangular with a yellow wrapper and a black label. The label displays key specifications like "Model No.: CS-UEA500BL", "Part No.: HBL6310", "Rating: 3.8VDC = 3650mAh 13.87Wh", and "Lithium-Polymer Battery Pack". Safety warnings and manufacturer information are also visible. A white connector with three colored wires (red, white, black) extends from one side.

4. Компатибилност

This battery is compatible with the following Urovo device models and battery part numbers:

Compatible Device Models:

• Urovo i6310i
• Urovo i6310
• Urovo i6310C
• Urovo i6310B
• Urovo i6310M7

Compatible Battery Part Numbers:

• ХБЛ6310

5. Техничке спецификације

6. Подешавање и инсталација

Battery replacement should be performed with care. If you are unsure about the process, it is recommended to seek professional assistance to avoid damage to your device or the new battery.

1. Уређај за искључивање: Ensure your Urovo device is completely powered off before beginning any installation steps.
2. Пронађите одељак за батерију: Refer to your device's original manual or manufacturer's guidelines for instructions on how to safely open the battery compartment.
3. Искључите стару батерију: Carefully disconnect the old battery's connector from the device's mainboard. Avoid pulling on the wires.
4. Уклоните стару батерију: Gently remove the old battery from its compartment.
5. Уметните нову батерију: Place the Enyuly HBL6310 battery into the compartment, ensuring proper orientation and fit. Do not force it.
6. Повежите нову батерију: Connect the new battery's connector securely to the device's mainboard. Ensure it clicks into place if applicable.
7. Безбедни одељак: Close and secure the battery compartment according to your device's design.
8. Почетна наплата: Fully charge the new battery before its first use to calibrate it and ensure optimal performance.

Опис слике: A detailed close-up of the three-pin battery connector (white housing with gold-colored pins) and its attached wires (red, white, black). This illustrates the precise connection mechanism that needs to be securely attached to the device's mainboard.

Опис слике: The Enyuly HBL6310 battery positioned next to a Urovo i6310 series device, illustrating the relative size and intended fit. The device is shown powered on with a "SAFEDROID" logo on its screen, providing visual context for the battery's application.

7. Упутство за употребу

Follow these guidelines for optimal performance and longevity of your new battery.

1. Прва употреба: After successful installation, fully charge the battery before using your device for the first time. This helps in calibrating the battery's charge indicator.
2. Пуњење: Use only the original or a certified compatible charger for your Urovo device. Avoid overcharging or deep discharging the battery, as this can reduce its lifespan.
3. Нормалан рад: The battery will provide power to your device as expected. Monitor battery levels and recharge as needed. Modern Li-Polymer batteries do not suffer from a 'memory effect', so you can charge them at any time.

8. Одржавање

Proper maintenance can extend the life of your battery.

• Складиштење: If storing the battery for an extended period (more than a month), ensure it is charged to approximately 50-60% and stored in a cool, dry place away from direct sunlight and extreme temperatures (below 0°C or above 30°C).
• Чишћење: Keep battery contacts clean and free from dust or debris. Use a dry, soft cloth for cleaning. Do not use liquids or abrasive materials.
• одлагање: Dispose of old batteries responsibly according to local regulations. Do not dispose of in household waste or fire. Many electronics stores or recycling centers offer battery recycling services.

КСНУМКС. Решавање проблема

If you encounter issues with your Enyuly HBL6310 battery, consider the following common troubleshooting steps:

• Батерија се не пуни:
  • Ensure the battery is correctly installed and the connector is secure within the device.
  • Verify that the charger and charging cable are functional by testing them with another device if possible.
  • Check for any physical damage to the battery or the device's charging port.
• Кратак век трајања батерије:
  • Ensure the battery has been fully charged after installation and before use.
  • Check device settings for power-intensive applications or features running in the background (e.g., GPS, Wi-Fi, high screen brightness).
  • Battery life naturally degrades over time and with usage cycles. If the battery is old, its capacity may have diminished.
• Уређај се не укључује:
  • Потврдите да је батерија потпуно напуњена.
  • Re-install the battery to ensure proper connection.
  • If the issue persists after trying the above steps, it may indicate a problem with the device itself rather than the battery. Consult your device's manufacturer for further assistance.

10. Гаранција и подршка

Enyuly provides 1 year of after-sales service for this replacement battery, ensuring your satisfaction and product reliability.

For warranty claims or technical support, please contact Enyuly customer service through your purchase platform or refer to the contact information provided with your product packaging.

For general product information, you may also visit Cameron Sino.
