SOOMFON BT32 Dual Antenna Bluetooth 5.3 Transmitter Receiver User Manual

1. Увод

The SOOMFON BT32 is a versatile 3-in-1 Bluetooth 5.3 audio adapter designed to enhance your audio experience. It functions as a Bluetooth transmitter (TX mode), a Bluetooth receiver (RX mode), and supports a direct audio bypass mode. Featuring a dual-antenna design for stable signal transmission and an LCD display for clear operation, the BT32 allows you to wirelessly stream audio from non-Bluetooth devices like TVs to Bluetooth headphones, or stream audio from your phone to wired speakers. It also supports simultaneous connection to two devices.

2. Садржај пакета

Молимо вас да проверите да ли су све ставке присутне у пакету:

• Bluetooth Audio Adapter (BT32) x 1
• 3.5mm Aux to RCA Cable x 1
• 3.5 мм аудио кабл к 1
• Оптички кабл к 1
• USB-C Power Cable x 1
• Упутство за употребу к 1

Image: The SOOMFON BT32 Bluetooth adapter and its included accessories: 3.5mm Aux to RCA cable, 3.5mm audio cable, optical cable, USB-C power cable, and user manual.

3. Производ је готовview

The BT32 features a clear LCD display, intuitive control buttons, and a multi-function volume knob. It is equipped with dual antennas for enhanced signal stability. Various audio input and output ports are located on the rear panel for flexible connectivity.

Слика: Крупни план view of the SOOMFON BT32 showing its LCD display, control buttons, volume knob, and rear panel with Type-C Power Input, Optical Input, 3.5mm Input, 3.5mm Output, and Optical Output ports.

4. Подешавање и повезивање

4.1 Укључивање

1. Connect the provided USB-C Power Cable to the "DC IN" port on the BT32 and plug the other end into a 5V USB power adapter (not included) or a USB port on your TV/PC.
2. Long press the power button (rightmost button) on the BT32 to turn it on. The LCD screen will illuminate.

4.2 Подешавање режима предајника (TX)

Use TX mode to transmit audio from your TV, PC, or other non-Bluetooth audio source to Bluetooth headphones or speakers.

1. Уверите се да је БТ32 укључен.
2. Press the middle button to switch the device to TX mode (indicated on the LCD screen).
3. Connect the BT32 to your audio source (e.g., TV) using one of the following cables:
   • оптички кабл: Connect from your TV's Optical Out to the BT32's "SPDIF IN" port.
   • 3.5 мм аудио кабл: Connect from your TV's 3.5mm Audio Out (headphone jack) to the BT32's "AUX IN" port.
   • 3.5mm Aux to RCA Cable: Connect the 3.5mm end to the BT32's "AUX IN" port and the RCA ends to your TV's RCA Audio Out ports (red and white).
4. Set your Bluetooth headphones or speakers to pairing mode.
5. The BT32 will automatically search for nearby Bluetooth devices. Once your device appears on the LCD, click the volume knob to confirm and wait for the connection.
6. To connect a second pair of headphones/speakers, click the left button to search for the second device, then click the volume knob to confirm.

Image: Two individuals wearing Bluetooth headphones, connected to the SOOMFON BT32, enjoying audio from a TV in Transmitter Mode.

4.3 Подешавање режима пријемника (RX)

Use RX mode to receive audio from your Bluetooth-enabled phone, tablet, or laptop and play it through wired speakers or a home stereo system.

1. Уверите се да је БТ32 укључен.
2. Press the middle button to switch the device to RX mode (indicated on the LCD screen).
3. Connect the BT32 to your wired speaker or stereo system using one of the following cables:
   • оптички кабл: Connect from the BT32's "SPDIF OUT" port to your speaker/stereo's Optical In.
   • 3.5 мм аудио кабл: Connect from the BT32's "AUX OUT" port to your speaker/stereo's 3.5mm Audio In.
   • 3.5mm Aux to RCA Cable: Connect the 3.5mm end to the BT32's "AUX OUT" port and the RCA ends to your speaker/stereo's RCA Audio In ports.
4. On your phone, tablet, or laptop, enable Bluetooth and search for "BT32" in the list of available devices.
5. Select "BT32" to pair. Confirm any pairing requests.
6. To connect a second mobile device, ensure the first device is connected, then search for "BT32" on the second device and pair. You can switch between the two connected devices for audio playback.

Image: The SOOMFON BT32 in Receiver Mode, connected to a stereo system with two speakers, while two smartphones are actively streaming music to it.

4.4 Bypass Mode Setup

Bypass mode allows for a direct wired connection, passing audio through the BT32 without Bluetooth functionality. This is useful for systems where you want to switch between wired and wireless audio without re-cabling.

1. Уверите се да је БТ32 укључен.
2. Press the middle button to switch the device to Bypass mode (indicated on the LCD screen).
3. Connect your audio source (e.g., TV) to the BT32's input ports (e.g., "SPDIF IN" or "AUX IN").
4. Connect the BT32's output ports (e.g., "SPDIF OUT" or "AUX OUT") to your wired speaker or stereo system.
5. Audio will now pass directly from your source to your speakers through the BT32.

Image: A diagram illustrating the Bypass Mode setup, where the BT32 connects a TV to an AV receiver, allowing audio to be output to wired speakers or headphones without Bluetooth.

5. Упутство за употребу

5.1 Промена режима

Press the middle button on the BT32 to cycle through the three modes: Transmitter (TX), Receiver (RX), and Bypass. The current mode is displayed on the LCD screen.

5.2 Pairing and Reconnection

• Прво упаривање: In TX or RX mode, the BT32 will automatically enter pairing mode and search for devices. Follow the steps in Section 4 to connect your desired Bluetooth devices.
• Аутоматско поновно повезивање: Once paired, the BT32 will automatically reconnect to previously paired devices when they are within range and in pairing mode.
• Двострука веза: The BT32 supports connecting to two Bluetooth headphones/speakers in TX mode, or two mobile devices in RX mode. In RX mode, only one device can play audio at a time; switch between them as needed.

5.3 Контрола јачине звука

The large rotary knob on the right side of the BT32 controls the audio volume. Rotate it clockwise to increase volume and counter-clockwise to decrease volume. Press the knob to pause or play audio.

Image: A close-up of the SOOMFON BT32's LCD display showing connection status and the prominent volume control knob.

КСНУМКС. Решавање проблема

• Нема звука:
  • Ensure all cables are securely connected to the correct input/output ports on both the BT32 and your audio devices.
  • Verify the BT32 is in the correct mode (TX for transmitting, RX for receiving, Bypass for direct connection).
  • Check the volume levels on both the BT32 and your connected audio devices.
  • Confirm that your TV/audio source is outputting audio through the selected port (e.g., Optical Out, Aux Out). Some TVs require manual selection in their audio settings.
  • If using optical, ensure your TV's audio output format is set to PCM/Stereo, not Dolby/DTS.
• Проблеми упаривања:
  • Ensure your Bluetooth headphones/speakers or mobile device is in pairing mode.
  • Move the BT32 closer to the device you are trying to pair.
  • Clear the Bluetooth pairing list on your device and the BT32 (refer to the full manual for specific steps if available).
  • Рестартујте и BT32 и ваш Bluetooth уређај.
• Intermittent Connection/Poor Range:
  • Ensure the dual antennas on the BT32 are upright and unobstructed.
  • Reduce the distance between the BT32 and your connected Bluetooth device.
  • Minimize physical obstructions (walls, large furniture) and electronic interference from other wireless devices.

7. Спецификације

8. Одржавање

• Одржавајте уређај чистим тако што ћете га обрисати меком, сувом крпом.
• Избегавајте излагање уређаја екстремним температурама, директној сунчевој светлости или високој влажности.
• Не покушавајте сами да растављате или поправљате уређај. За помоћ контактирајте подршку.
• Handle batteries according to local regulations and dispose of them properly.

9. Гаранција и подршка

The SOOMFON BT32 comes with a generous 24-месечна гаранција на производ. We also provide доживотна техничка подршка to ensure your satisfaction. Our dedicated support team is available 7 дана у недељи, 24 сата дневно. If you encounter any issues or require assistance, please do not hesitate to reach out to us.

For prompt support, please contact us at: суппорт@соомфон.цом
